GE VersaMax Micro Analog Expansion Unit PLC IC200ALG620
Product Describe
RTD and Thermocouple Modules
Specialty modules are available for RTD and Thermocouple inputs . Modules require a carrier base
(IC200CHSxxx) .) .
| | IC200ALG620 | IC200ALG630 |
| Product Name | VersaMax Analog Input Module,
16 Bit RTD, 4 Channel | VersaMax Analog Input Module,
16 Bit Thermocouple, 7 Channel |
| Lifecycle Status | Active | Active |
| Input Range | RTD types: 25, 100, and 1000 ohm platinum
10, 50, and 100 ohm copper 100 and
120 ohm nickel 604 ohms nickel/iron | Thermocouple types:
J, K, T, S, R, none (used for mV inputs) |
| Number of Channels | 4 | 7 |
| Resolution | 15 bits plus sign | 15 bits plus sign |
| Update Rate | 60 Hz: approximately 210 milliseconds per channel 50 Hz:
approximately 230 milliseconds per channel | 60 Hz: approximately 60 milliseconds per channel 50 Hz:
approximately 70 milliseconds per channel |
| Accuracy at 25°C | on voltage measurement: ±0 .15% on resistance measurement
on temperature measurement: ±0 .15% on RTD
(temperature) measurement | on voltage measurement: ±0 .2%
on temperature measurement:±0 .15% |
5 V Backplane Current
Consumption (mA) | 125 maximum | 125 maximum |
3 .3 V Backplane Current
Consumption (mA) | 125 maximum | 125 maximum |
| LED Indicators | OK LED: green indicates backplane power is present .
Amber indicates module fault | OK LED: green indicates backplane power is present .
Amber indicates module fault |
| Dimensions (W x H x D) | 110 mm (4 .3 in) x 66 .8 mm (2 .63 in) x 50 mm (1 .956 in),
not including the height of the carrier or the
mating connectors | 110 mm (4 .3 in) x 66 .8 mm (2 .63 in) x 50 mm (1 .956 in),
not including the height of the carrier or the
mating connectors |
